Product Specifications

Part Number:57612
UPC Number:765809576124
Style:Spin-On Hydraulic Filter
Service:Hydraulic
Type:Full Flow
Media:Cellulose
Height:5.52 (140)*
Outer Diameter Top:3.13 (80)*
Outer Diameter Bottom:Closed:
Thread Size:2-12
(  )* denotes metric

Gasket Diameters

NumberO.D.I.D.Thk.
Attached 2.135 (54)*1.865 (47)*0.135 (3)*

Principle Application:

Principle Application:Replacement element for Donaldson HMK03 Hydraulic Assembly
