Product Specifications

Part Number:R26D10GP
UPC Number:765809700581
Style:Cartridge Hydraulic Metal Canister Filter
Service:Hydraulic
Type:Full Flow
Media:Microglass
Height:32.48 (825)*
Outer Diameter:7.953 (202)*
Inside Diameter Top:6.181 (157)*
Inside Diameter Bottom:0.559 (14)*
Thread Size:
Beta Ratio:200/9.9
Nominal Micron Rating:10
Operating Temp. (min):-13
Operating Temp. (max):248
Flow Direction:Inside-Out
Capacity:558.12
Filter Area:5701
(  )* denotes metric

Gasket Diameters

NumberO.D.I.D.Thk.
Attached 0.0 ()*0.0 ()*0.0 ()*

Principle Application:

Principle Application:Various Industrial Hydraulic Applications
All Applications
