Product Specifications

Part Number:W01AG139
UPC Number:765809366701
Style:Cartridge Hydraulic Metal Canister Filter
Service:Hydraulic
Type:Full Flow
Media:Microglass
Height:24.65 (626)*
Outer Diameter:5.98 (152)*
Inside Diameter Top:3.5 (89)*
Inside Diameter Bottom:3.35 (85)*
Beta Ratio:200/9.9
Nominal Micron Rating:10
Operating Temp. (min):-13
Operating Temp. (max):248
Flow Direction:Inside-Out
Capacity:221.81
Filter Area:2470
(  )* denotes metric

Gasket Diameters

NumberO.D.I.D.Thk.
Attached 0.0 ()*0.0 ()*0.0 ()*

Principle Application:

Principle Application:Various Industrial Hydraulic Applications
All Applications
