Product Specifications

Part Number:W01AG703
UPC Number:765809367500
Style:Cartridge Hydraulic Metal Canister Filter
Service:Hydraulic
Type:Full Flow
Media:Microglass
Height:9.49 (241)*
Outer Diameter:2.87 (73)*
Inside Diameter Top:1.07 (27)*
Inside Diameter Bottom:Closed:
Beta Ratio:200/9.9
Nominal Micron Rating:10
Operating Temp. (min):-13
Operating Temp. (max):248
Flow Direction:Outside-In
Filter Area:599
(  )* denotes metric

Gasket Diameters

NumberO.D.I.D.Thk.
Attached 0.0 ()*0.0 ()*0.0 ()*

Principle Application:

Principle Application:Various Industrial Hydraulic Applications
All Applications
