Product Specifications

Part Number:51174
UPC Number:765809511743
Style:Spin-On Hydraulic Filter
Service:Hydraulic
Type:Full Flow
Media:Wire Mesh
Height:4.363 (111)*
Outer Diameter Top:3.698 (94)*
Outer Diameter Bottom:Closed:
Thread Size:1 1/8-16
Burst Pressure-PSI:280
Max Flow Rate:18-20 GPM
Nominal Micron Rating:150
(  )* denotes metric

Gasket Diameters

NumberO.D.I.D.Thk.
Attached 2.729 (69)*2.415 (61)*0.255 (6)*

Principle Application:

Principle Application:Massey-Ferguson Tractors (Wire Mesh)
All Applications
Best viewed in Chrome, Firefox, IE9 and above

Part Number: 51174

Error: Embedded data could not be displayed.


For reference only. There are no express or implied warranties with respect to products selected by size, feature or cross reference. Warranties only apply to products selected according to the Vehicle Application Listing. No product has been certified or warrantied for Aviation use.
