Product Specifications

Part Number:33195
UPC Number:765809331952
Style:Spin-On Fuel Filter
Service:Fuel
Type:
Media:Enhanced Cellulose
Height:4.077 (104)*
Outer Diameter Top:3.015 (77)*
Outer Diameter Bottom:Closed:
Thread Size:16X1.5 MM
Burst Pressure-PSI:290
Max Flow Rate:6-8 GPM
Nominal Micron Rating:10
(  )* denotes metric

Gasket Diameters

NumberO.D.I.D.Thk.
Attached 2.74 (70)*2.37 (60)*0.275 (7)*
Packed 0.871 (22)*0.595 (15)*0.143 (4)*

Principle Application:

Principle Application:Bobcat, Bomag, Ditchwitch, Deutz engines, Ford Trks, Other (10 Micron) - shorter version, use 33361, for longer version, use 33358 or 33373
